Model
|
L-V-680
|
L-V-800
|
L-V-SS
|
L-V-DS
|
|
External Size
(W*D*H)
|
680*410*1160mm
|
802*650*1550mm
|
1040*615*1770mm
|
1440*615*1770mm
|
|
Internal Size
(W*D*H)
|
630*375*615mm
|
800*600*540mm
|
940*540*545mm
|
1340*540*545mm
|
|
Work Surface
Height
|
/
|
660mm
|
750mm
|
750mm
|
|
Display
|
LED Display
|
|
Airflow Velocity
|
Average of 0.3~0.5m/s, air speed adjustable
|
|
Material
|
Main Body: Cold-rolled steel with anti-bacteria powder coating
|
|
Work Table: 304 stainless steel
|
|
Pre-filter
|
Polyester fiber, washable
|
|
HEPA Filter
|
99.999% efficiency at 0.3um
|
|
Noise
|
<60dB
|
|
Front Window
|
/
|
Manual, 5mm toughened glass, anti-UV
|
|
Max Opening
|
/
|
490mm
|
310mm
|
310mm
|
|
Illuminating Lamp
|
Florescent lamp
14W*1
|
LED lamp
8W*1
|
LED lamp
12W*1
|
LED lamp
16W*1
|
|
UV Lamp
|
15W*1
|
20W*1
|
18W*1
|
30W*1
|
|
Emission of 253.7 nanometers
|
|
Consumption
|
160W
|
350W
|
350W
|
600W
|
|
Caster
|
/
|
Universal wheel with leveling feet
|
|
Power Supply
|
AC220V±10%, 50/60 Hz; 110V±10%, 60HZ
|
|
Standard Accessory
|
Fluorescent lamp for model L-V-680, LED lamp(for model L-V-800/SS/DS) UV lamp*2 ( for all models )
Water & gas tap (for model L-V-V680)
Base stand (except model L-V-V680)
|
|
Gross Weight
|
50kg
|
116kg
|
131kg
|
174kg
|
|
Package Size (W*D*H)
|
840*560*1380mm
|
960*800*1800mm
|
1190*890*1340mm
|
1590*890*1330mm
|
