Introduction:
Root analysis system is based on image recognition technology, it is professionally used for root analysis of plants after
washing the roots in vitro. It has the characteristics of convenience, efficiency and high accuracy, which can improve the
work efficiency of practitioners, reduce labor costs.
Features:
* Clear interface design, modular function design.
* User learning cost is lower, operation is more convenient and smoother.
* The analysis results are more accurate.
Technical Parameter:
|
Model
|
MF-RS-A
|
|
Power Supply
|
100~240V,50/60Hz
|
|
Optional Accessory
|
computer
|
|
Package Size
|
805*235*395mm
|
|
Net Weight
|
8kg
|
|
Gross Weight
|
9.7kg
|
Overall Analysis Parameter:
|
Model
|
MF-RS-A
|
|
Root Tip
|
Number: the total number of root tips, equal to the number of termination points
|
|
Range
|
0~1000
|
|
Accuracy
|
error<5%
|
|
Root System
|
Length: total root system length, including main root and secondary roots
|
|
Range
|
0~10000mm
|
|
Accuracy
|
error<3.65%
|
|
Average Diameter: the average diameter of the root system
|
|
Range
|
0~20mm
|
|
Accuracy
|
error<0.04%
|
|
Projected Area: the projected area of the root system as a whole
|
|
Range
|
0~200000mm²
|
|
Accuracy
|
error <4.02%
|
|
Surface Area: the overall surface area
|
|
Range
|
0~1000000mm²
|
|
Accuracy
|
error<3.75%
|
|
Volume: overall volume
|
|
Range
|
0~2000000000mm³
|
|
Accuracy
|
error<3.82%
|
Topological Analysis Parameter (requires relatively complete root system):
|
Model
|
MF-RS-A
|
|
Quantity: the sum of the number of roots at all levels
|
|
Range
|
0~100
|
|
Number of Connections: the sum of the number of connections on the side roots at all levels
|
|
Range
|
0~100
|
|
Length: the sum of the lengths of the lateral roots at all levels
|
|
Range
|
0~10000mm
|
|
Diameter: the average diameter of each side root
|
|
Range
|
0~20mm
|
|
Surface Area: the sum of the surface area of each side root
|
|
Range
|
0~1000000mm²
|
|
Volume: the sum of the volume of each side root
|
|
Range
|
0~2000000000mm³
|
|
Projected Area: the sum of the projected area of each side root
|
|
Range
|
0~200000mm²
|
